Aruba 5406R 16SFP+ v3 zl2 Switch (JL095A)
Rp203.053.410
- Powerful Aruba Layer 3 modular switch series with VSF stacking, low latency and resiliency.
- HPE Smart Rate for high-speed multi-gigabit bandwidth and PoE+ power.
- Scalable line rate 40GbE for wireless traffic aggregation.
JL095A Specification |
|
| Type | HPE 5406R 16-port SFP+ (No PSU) v3 zl2 Switch |
| Included accessories | 1 HPE 5400R zl2 Management Module (J9827A)
1 HPE 5406R zl2 Switch Fan Tray (J9831A) 2 HPE 8-port 1G/10GbE SFP+ MACsec v3 zl2 Module (J9993A) |
| I/O ports and slots | 16 open 10GbE SFP+ transceiver slots
4 open module slots Supports a maximum of 144 autosensing 10/100/1000 ports or 144 SFP ports or 48 SFP+ ports or 48 HPE Smart Rate Multi-Gigabit or 12 40GbE ports, or a combination |
| Power supplies | 2 power supply slots 1 minimum power supply required (ordered separately) |
| Fan Tray | Includes: 1 x J9831A
1 fan tray slot |
| Dimensions (W x D x H) | 17.5(w) x 17.75(d) x 6.9(h) in. (44.45 x 45.09 x 17.53 cm) (4U height) |
| Weight | 28.11 lb (12.75 kg) |
Memory and processor |
|
| v3 Gigabit Module | Dual ARM® Coretex A9 @ 1 GHz; Packet buffer size: 13.5 MB internal |
| v2 Gigabit Module | ARM 11 @ 450 MHz; Packet buffer size: 18 MB internal |
| v3 10G Module | Dual ARM Coretex A9 @ 1 GHz; Packet buffer size: 13.5 MB internal |
| v2 10G Module | ARM 11 @ 550 MHz; Packet buffer size: 18 MB internal |
| v3 40G Module | Dual ARM Coretex A9 @ 1 GHz; Packet buffer size: 13.5 MB internal |
| Management Module | Freescale P2020 dual core @ 1.2 GHz, 16 MB flash, 1 GB SD Card, 4 GB DDR3 SODIMM |
| Mounting and enclosure | Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware included); Horizontal surface
mounting only |
| Performance (IPv6 Ready Certified) | |
| 1000 Mb Latency | < 2.8 µs (FIFO 64-byte packets) |
| 10 Gbps Latency | < 1.8 µs (FIFO 64-byte packets) |
| 40 Gbps Latency | < 1.5 µs (FIFO 64-byte packets) |
| Throughput | up to 571.4 Mpps |
| Routing/Switching capacity | 960 Gbps |
| Switch fabric speed | 1015 Gbps |
| Routing table size | 10000 entries (IPv4), 5000 entries (IPv6) |
| MAC address table size | 64000 entries |
| Environment | |
| Operating temperature | 32°F to 113°F (0°C to 45°C); 0°C to 40°C with J8177C transceiver installed, 0°C to 35°C with FIPS Opacity
Shield installed |
| Operating relative humidity | 15% to 95% @ 113°F (45°C), noncondensing |
| Nonoperating/Storage temperature | -40°F to 158°F (-40°C to 70°C) |
| Nonoperating/Storage relative humidity | 15% to 95% @ 149°F (65°C), noncondensing |
| Altitude | Up to 10,000 ft (3 km) |
| Acoustic | Power: 44 dB, Pressure: 31.7 dB ISO 7779, ISO 9296 |
| Electrical characteristics | |
| Frequency | 50/60 Hz |
| 80plus.org Certification | Gold |
| Description | Does not come with power supply. Two power supply slots are available; three different power supplies are
available. See power supply products for additional specifications. |
| Maximum heat dissipation | 2450 BTU/hr (2584.75 kJ/hr), (max. non-PoE);
3700 BTU/hr (3903 kJ/hr), (max. using PoE) |
| Voltage | 110–127/200–240 VAC, rated (depending on power supply chosen) |
| Idle power | 215 W |
| Notes | Idle power is the actual power consumption of the device with no ports connected. Heat dissipation does
not include heat dissipated by the PoE-powered devices themselves |
| Safety | CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950 |
| Emissions | FCC part 15 Class A; EN 55022/CISPR 22 Class A |
| Immunity
EN ESD Radiated EFT/Burst Surge Conducted Power frequency magnetic field Harmonics Flicker |
EN 55024, CISPR 24
IEC 61000-4-2; 4 kV CD, 8 kV AD; HPE ENV. 765.002 IEC 61000-4-3; 3 V/m IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line) IEC 61000-4-5; 1 kV/2 kV AC, 1 kV signal, 0.5 kV DC IEC 61000-4-6; 3 Vrms IEC 61000-4-8; 1 A/m, 50 or 60 Hz IEC 61000-4-11; >95% reduction, 0.5 period; 30% reduction, 25 periods EN 61000-3-2, IEC 61000-3-2 EN 61000-3-3, IEC 61000-3-3 |
| Management | IMC—Intelligent Management Center; Command-line interface; Web browser; Configuration menu; Out-of-band
management (RJ-45 Ethernet); SNMP Manager; Out-of-band management (serial RS-232C or micro USB) AirWave Network Management |
| Notes | Supported 1G SFP transceivers are revision “B” or later (product number ends with the letter “B” or later;
For example, J9142B, J8177C). |
